Ingersoll-Rand - UP-Series 5-15 HP - The high efficiency compressor room without the need for an actual room.
- Ultimate Reliability
- Maximum Uptime
- 70% Fewer Connections
- Ultimate Efficiency
- More Air For Your Money
- Smart, Energy Efficient Controls
- Ultimate Flexibility
- Compact Footprint Design
- Installation Close To Point-of-use
- Ultimate Productivity
- Closely Maintained Pressure
- Innovation
- High Efficiency Integrated Compression Module
- Dry & Clean Compressed Air - The right air quality to do the job. All Total Air System packages come fully equipped with an integral, energy saving air treatment center including high performance air dryer and filtration pack to remove water, oil and particles from the air stream. All components are perfectly matched to deliver the right air quality to increase air powered tool and system equipment life.
- High Efficiency Components - Setting the standard in system design. The UP Series Total Air System incorporates only the highest quality components to ensure that both system efficiency and productivity are maximized. A high efficiency compressor room without the hassle, complexity and costs of the traditional compressor room. Total Air System packages come fully equipped with...
- High Efficiency Rotary Screw Air Compressor.
- Energy Saving, Cycling Refrigerated Air Dryer.
- High Efficiency Coalescing Filter.
- High Efficiency Particulate Filter.
- Integral Air Receiver Storage Tank.
- Integrated Compressor and Dryer Controls.
- Low Pressure Drop Piping.
- High Efficiency Moisture Separator.
- Whisper Quiet, Low Sound Operation.
Saylor-Beall
- Available 15-100 HP.
- Oil flooded rotary screw air end is designed for 100% duty cycle.
- Spin on oil filter makes service easy.
- Direct drive, C-face in sizes 15 to 50 horsepower.
- Radiator type air cooled oil after cooler removes heat from discharge air and compressor oil.
- Oil separator tank with replacement element removes oil from compressed air and recycles into the compressor.
- Compressor control includes full voltage magnetic starter with circuit breaker. Solenoid style, unload control, full inlet modulation and timed unload control reduce costs of operation. Instrumentation includes air pressure gauge, oil temperature gauge and hour meter. All units are equipped with breakers and 110 volt control transformer.
GrimmerSchmidt Compressors - TS Series Industrial Air Compressors 10-40 HP - The TS Series of industrial air compressors are designed to provide dependable sources of high quality compressed air. The package requires minimal floor space, allows easy access to all service points, and dramatically reduces noise levels. Advanced compressor controls enable the user to raise or lower operating pressures with the touch of a button. In addition to product innovation, GrimmerSchmidt's personal approach to customer service treats all requests promptly and professionally and includes toll free sales and service numbers, internet communication and same day parts shipments.
- Oil flooded twin rotary screw encapsulated design.
- TEFC motor 208-230/460VAC meets EPAC ratings for efficiency
- NEMA 4 electrical enclosure(s).
- Sound attenuated enclosure 69-71 dBA @ 1 meter
- Easy lift-off or hinged panels (meets ANSI and OSHA machine safe guarding requirements).
- Spin-on oil filter and air/oil separator element.
- Air to air and air to oil aftercooler and oil cooler (accessible for easy cleaning).
- Virtually leak proof (all fittings above 1/8" are straight thread type with o-rings as seals).
Special requests/quotes available.
| | |
